JUKI LU 1560N Twin Needle Machine with Table and Motor

Description

Juki LU 1560N Twin Needle Machine with Table and Motor

Zero Sales Tax outside S.C.
2-Needle Unison Feed Lockstitch Industrial Machine with Table and Servo Motor (Table Comes Assembled)

JUKI’s unique feed mechanism promises excellent efficiency of feed. In addition to the standard models of 1-needle and 2-needle machines.

Other models intended for special purposes are available, including models for extra heavy materials as well as one having a thread trimmer.

The machine is applicable to an extended range of heavy materials for industrial use.

Examples such as cargo handling belts and containers, as well as those for general use, such as car seats, sofas and bags, thereby contributing to both improved quality and increased productivity.



• A new feed mechanism with a rectangular feeding motion prevents stitch gathering.

  • The new mechanism with a rectangular feeding motion promises consistent feed of materials of all thickness without stitch gathering.
  • The lower orbit of the feed dog prevents the material from flopping and reduces operating noise and vibration.



• The alternating vertical movement mechanism prevents irregular stitches.

  • The machine has adopted a new mechanism that does not change the ratio of alternate vertical movement of the walking foot and presser foot even when the material thickness changes.
  • Even when a heavy-weight material is used, the presser foot lift does not decrease.
  • This means that the presser foot comes into contact with the material at exactly the same time that it does when sewing lighter-weight sections of the material.
  • As a result, the walking foot retains the material with a consistent pressure to prevent irregular stitches.
  • The amount of the alternating vertical movement of the walking foot and presser foot can be adjusted up to the maximum of 6.5mm according to the height of multilayered portions of material.



Instruction manual

ASSEMBLED TABLE & SERVO MOTOR

This Package includes a Fully Assembled Table and a Servo Motor.

HIGHER LIFT OF THE PRESSER FOOT

^{The high, 16mm presser foot lift enables easy material handling.}

DOUBLE-CAPACITY HOOK

With the adoption of this vertical-axis double-capacity hook, the frequency of bobbin thread changing is reduced, promising sewing work of increased efficiency.

THREAD TRIMMING

The machine leaves a shorter needle thread after thread trimming, improving thread consumption efficiency. With a rigid knife and improved cam shape, the thread trimmer cuts thread as thick as #5 without fail.

THE AREA  AROUND THE NEEDLE ENTRY IS DESIGNED TO BE EASILY OBSERVED.

Since the needle thread tension-release solenoid is fitted on the rear face of the Juki industrial lockstitch machine head.

The area around the needle entry and one-touch type reverse feed button is easily viewable. This substantially contributes to improved operability.

IMPROVED OPERABILITY

The stitch length can be easily selected by the stitch dial.
The machine is provided with many improved features that offer enhanced operability.

Such as an easy-to-observe area around the needle, placement of the bobbin winder on the front face of the machine arm, and a large handwheel (φ 160).

A knee-lifter mechanism is built in the bed. This reduces the pressure required to operate the knee-lifter and facilitates setup. (Machines equipped with automatic thread trimmer are excluded.)

The machine is full-open-type top design makes it possible to fully open the top of the machine arm. Thanks to this design, adjusting works can be done without tilting the machine head.

The machine is equipped as standard with a safety clutch for preventing hook breakage. Reset work can be done simply by pressing a button

Manual

• Consistent seam quality.

  • With the adoption of a new rectangular feed mechanism, an alternating vertical movement mechanism, and a unison feed mechanism, the machine can feed heavy materials powerfully and smoothly.
• • Well tensed seams are consistently produced without pitch errors.
  • With its maximum stitch length of 9mm, the machine can be applied to a broader range of uses.



• Higher lift of the presser foot

  The high, 16mm (13mm for LU-1565N) presser foot lift enables easy material handling as well as thicker material sewing .



• The highly efficient vertical-axis double-capacity hook is equipped as standard

  With the adoption of this vertical-axis double-capacity hook, the frequency of bobbin thread changing is reduced, promising sewing work as well as increased efficiency.



• LU-1560N, LU-1561N
  (with automatic lubricating)

  • The standard 2-needle type machine that delivers the basic functions and performance best suited to the sewing of heavy materials.
  • Automatic lubricating mechanism improves maintainability. The sub oil pan and double filter prevent dust from entering the oil.

• Max. Sewing Speed: 2,500 Stitch per Minute.
• Max. Stitch Length: 9mm (forward / backward).
• Needle Bar Stroke: 36mm.
• Lift of the Presser Foot by Hand: 9mm.
• Lift of the Presser Foot by Knee: 16mm.
• Thread Take-Up: Slide Type.
• Amount of Altering Vertical Movement: 2.5~6.5mm.
• Hook: Horizontal-Axis Full-Rotary Double-Capacity Hook.
• Needle (at time of delivery): 135×17 (Nm160) Nm125~Nm180.
• Thread: #30~#5, B46~B138, Nm=60/3~15/3.

Maintenance.

• Pitch Changing Method: By Dial.
• Lubrication: Centralized Oil Wick.
• Lubricating Oil: Juki New Defrix oil No.2. (equivalent to ISO VG32).
• Distance from Needle to Machine Arm: 264mm.
• Bed Size: 477x178mm.
• Motor Output: 750W.
• The weight of the Machine Head: 36.5kg.

THE ADVANTAGES OF A SERVO MOTOR:

• They use up to 90% less power than clutch motors.
• In addition they are 1/3 lighter than clutch motors.
• With a flick of the switch you can reverse motor rotation.
• No parts to wear out or adjust.
• No matter how hard you press the foot pedal configured speed remains the same.

Because of Servo motor speed control, most users find the machine is easier to use.  Both beginning as well as seasoned sewers find this feature helpful when stitching projects that don’t demand high-speed stitching.

Features:
Adjustable Height.
Caster Wheels.
Heavy Duty Steel Construction.

Specification
